FA7-10C-A1S

FA7-10C(防塵)快速動作扳機開關

FA7-10C series (Dustproof) Snap-action Trigger Switches

產品描述Product description

◆FA7-10C系列是FA7-10系列的防塵改進款，內部為快速動作結構，內部具有良好的防塵性能，應用于對防塵要求較高的電動工具和園林工具，如：電圓鋸、曲線鋸、拋光機、電錘、電鎬、型材切割機、斜切鋸等。
◆FA7-10C series are updated type of FA7-10 series, with snap-action structure, integrated high grade dustproof, for used in power-tools and gardening tools such as Circular Saws, Jig Saws, Polishers Grinders, Rotary Hammers, Demolition Hammers, Miter Saws, Cut-off Machines, etc.

產品特征Features

◆可選帶以下鎖定類型 Optional with following lock types:
→無鎖定 No Lock
→閉合鎖定 Lock-on
→斷開鎖定 Lock-off
◆可選帶以下功能或附件 Optional with following function or accessories:
→雙極常開 DPNO
→單極常開 SPNO
→一極常開，另一極常閉 One Pole Normally Open, the other normally close
→帶軟膠扳機Trigger covered with rubber (Overmolding)

技術數據Technical data

→機械耐久壽命 Mechanical life endurance≥1E5
→電氣耐久壽命 Electrical life endurance≥5E4
→最大沖擊電流 Max.Inrush current at 250V90A
→最大沖擊電流 Max. Inrush current at 127V120A
→接觸電阻 Contact resistance≤30m Ohm
→絕緣電阻 Insulation resistance≥7M  Ohm
→基本介電強度 Dielectric strength of function1500V
→加強介電強度 Dielectric strength of reinforced3000V
→環境溫度 Ambient temperature0°C~55°C
→阻燃等級 FlammabilityUL 94V-0
→防護等級 Protection typeIP40
→適用于II類防護器具 Suitable for appliances of protection class II

端子類型Terminals

◆輸入端/輸出端 Input side/Output side:
→接線柱端子 Pillar terminals φ=3.5mm
★本產品榮獲實用新型專利，專利號：ZL201920475212.3
★Utility Model patented with the no. is ZL201920475212.3

電氣參數和認證 Electric Rating and Certification

訂貨信息Ordering Information
